1/5/10/20pcs 6KG Digital Servo Waterproof Scx10 Mn99s Mn86 12428 124018 124019 1/10(20pcs Metal 6KG)

Description

• Servo Gears

Servo Gears
Specification:
Product Name: S013Q
Quantity: 1/5/10/20 pieces
Working voltage: 4.8~6.0V DC
Maximum torque: 4.8~6.0kgf.cm; 6.0~7.5kgf.cm
No-load speed: 4.8V0.18s/60; 6.0V0.16s/60
Maximum operating travel angle: 18010 (500~2500 us)
Dead zone width: 5us
Mechanical limit angle: 360
Communication interface: PWM
Motor type: Iron core motor
Case material: ABS
Gear set material: plastic gear
Weight: 52 g
Dimensions: 49.520.236.64mm
Cable length: JR 250MM5mm
Package Included:
1/5/10/20 * 6KG digital servo
1/5/10/20 * Servo arm accessories
6KG Metal Version:
Specification:
Product name: S01 Quantity: 1/5/10/20 pieces
Working voltage: 4.8~6.0V DC
Maximum torque: 4.8V6.0kgf.cm; 6.0V6.8kgf.cm
No-load speed: 4.8V0.23s/60; 6.0V0.21s/60
Stalled rotor current: 4.8V 2100mA; 6.0V 2400mA
Current consumption* (no load): 4.8V 130mA; 6.0V 140mA
Maximum operating travel angle: 18010 (500~2500 us)
Dead zone width: 5us
Mechanical limit angle: 360
Communication interface: PWM
Motor type: Iron core motor
Case material: ABS
Gear set material: metal gear
Weight: 49 g
Dimensions: 49.520.236.64mm
Cable length: JR 250MM5mm
Package Included:
1/5/10/20* 6KG digital servo
1/5/10/20 * Servo arm accessories
