Description
- Servos
Servos
Specification:
Brand: E-Power
Model: HB8160GS
Color: Black
Control angle: 180/270/360 optional
Dead band width: 1 usec
Gear material: Metal gear
Case material: Aluminum case
Control system: PWM control (center point 1500usec)
Working voltage range: 10.0V~15V
Operating temperature range: -20C~ +60C
Cycle times: >1 million times (no load)
Operating stroke: 601
Limit angle: 1801/2701/3601
Direction: Clockwise/Pulse travel 500-2500 seconds
Diver Type: Mos Drive
Motor type: brushless motor
Potentiometer Type: Direct Drive
Amplifier Type: Digital Control
Static torque: 0.15sec/60, 48kg-cm@10.0V;
0.13 sec/60, 55 kg-cm@12V
0.11 sec/60, 60 kg-cm@14V
Idle current: 300mA@10.0V; 400mA@12V; 450mA@14V
Operating current: 4000mA@10.0V; 4500mA@12V; 5500mA@14V
Ball bearing: 2BB
Connector cable length: 300MM JR JST
Connector wire gauge: 22AWG
Wire information (brown): negative pole
Wire information (red): positive
Wire information (black): negative
Wire information (yellow): S single
Dimensions: 40x20x40.5mm
Weight: 83g (excluding servo speaker)
Equipped with 25T metal servo arm
Tips: Our 360-degree servo has a built-in adjustable potentiometer, so the left and right sides of the middle track rotate 180 degrees, not 360 degrees.
Package Included:
1 server
1 x Servo Accessory
