Description
- Use Attention: Used to extend the servo angle, the angle is initially controlled to 90 degrees, and then expanded to control 180 degrees. It does not directly change 90 degrees to 180 degrees.
- How to Use:: The servo is usually 180 degrees, but the remote control can only rotate it 90 degrees. The remote control pwm output is 1000-2000us. At this time, the servo can rotate 90 degrees. The device expands it to 500-2500us to achieve a 180-degree rotation. purpose.
- Widely Applicable: This servo angle extender is not only suitable for remote control cars and boats, but also suitable for robots. It is worthy of choice for remote control car enthusiasts, boat enthusiasts and robot enthusiasts.
- Easy Installation: The RC servo angle extender is small in size, light in weight, and easy to install and disassemble.
- Guarantee: If you are not satisfied with our product you received, you can send emails to us at any time. We will reply you instantly and help you solve your problem.
Specification:
Item Type: Servo Angle Expander
Material: Electronic Component
Color: As Picture Shown
Length: Approx. 134mm/5.3in
Weight: Approx. 4.0g/0.14oz
Applicable Voltage: 3.6-16V
Quantity: 1Pcs
Application: RC Car/Boat, Robot, etc.
How to use:
The servo is usually 180 degrees, but the remote control can only rotate it 90 degrees
The remote control pwm output is 1000-2000us, at this time the steering gear can be rotated 90 degrees
The device expands it to 500-2500us to achieve the purpose of rotating 180 degrees
Prerequisite: The steering gear can rotate 180 degrees in the range of 500-2500us.
Package List: 1 x Servo Angle Expander
Note: Used to extend the servo angle, the angle is initially controlled to 90 degrees, and then expanded to control 180 degrees.It does not directly change the 90 degree to 180 degrees.
